• DRV: 12 LEDs x 4W (48W) + POS: 9 x 0.5W (4.5W)
• Nominal Current @ 12V: DRV: 2.51A, POS: 0.125A
• Nominal Current @ 24V: DRV: 1.25A, POS: 0.0625A
• Rated IP66 / IP6K9K
• Housing: Graphene
• Lens: Anti-UV PC with hardening process
• Stainless Steel Mount, M8 / M10 Bolt
• Built in Plug-In Connector
• Illumination Angle: (H) 22° @1000CD, (V) 5° @1000CD
• 275m Light Distance
• Driving & Position Light Beam
• Cable Length: 400mm
• 244.4mm (L) x 138.4mm (W) x 110mm (H)
• ECE Reg 112/ Reg 149 (Driving Lamp) / R148 (Position Lamp)
• ECE Approved REG 10
• EMC CISPR25 CLASS 5
• Operating Temp: -40ºC to +50ºC
